High Reliability SEM 655D 5 Tons Wheel Loader For DRC

Introduction



The SEM 655D 5-ton wheel loader provides proven durability and an excellent cost-to-performance ratio for the DRC demanding copper-cobalt extraction and mineral transport sectors.

The premium operator station features an ergonomic layout equipped with patented MAC mounts, an adjustable suspension seat, and fresh air air conditioning, while its design effectively isolates operators from extreme external noise and harsh mining dust.

This heavy loader serves as a highly economical and practical hauling option for overburden stripping, hopper feeding, and the continuous transport of highly abrasive minerals





What Is a SEM 655D Wheel Loader?



The heavy earthmoving machine customized for the African mining market combines the widely used Weichai WD10G engine, a massively reinforced chassis frame. It boasts the following specialized configurations:



● Low-speed engine equipped with an E-fan, ensuring stable cooling performance and increased fuel efficiency under the scorching Central African sun.

● Twin pump flow merging hydraulic system, providing essential auxiliary lifting power and minimizing machine cycle times to 9.5 seconds.

● Countershaft power shift transmission with upgraded core components, safeguarding the drivetrain from severe torque impacts on rugged terrain.

● Advanced air cleaner paired with an enhanced fuel pre-filter, eliminating water and contaminants to deliver necessary engine protection in dust-intensive mining environments.



It is exceptionally well-suited to the actual operating conditions of mining sites in Central Africa, delivering outstanding performance in terms of reliability and fuel economy.





Technical Specifications



Feature	Value
Engine Model	WEICHAI WD10G
Power	162kW@2000r/min
Rated Load	5000kg
Operating Weight	16800kg
Bucket Capacity	2.7-4.5 m3
Transmission Type	Conuntershaft power shift
Hydraulic Cycle Time	9.5s
Breakout Force	168kN
Dump Clearance	3058mm
Tyre Size	23.5-25(16 Layer L3/B3 Bias)



Why It Is Suitable for DRC Mining Projects



1.Demanding Pit Road Conditions

DRC copper-cobalt mine roads typically feature:

● Deep mud, steep inclines, and unpaved laterite tracks

● Tight hopper corners requiring precise maneuverability

● Jagged, highly abrasive rock and compacted mineral surfaces

● Continuous heavy-duty loading and carry operations

The Weichai WD10G engine and countershaft transmission deliver massive torque and large 1st-gear rim-pull for steep ramps, while the high-efficiency drivetrain withstands severe rocky terrain.



2.Hot Climate and Heavy-Duty Challenges

Central African mining environments expose loaders to:

● Relentless high ambient temperatures under the direct sun

● Intense heat generated during slow, heavy-duty bucket loading

● Severe dust that easily clogs standard filtration systems

● Risk of hydraulic thermal decay during continuous shifts

The standard 50°C cooling package prevents engine and hydraulic overheating, and the heavy-duty air cleaner minimizes dust intake to ensure highly reliable engine performance.



3.High-Density Ore Material Demands

Handling raw, heavy copper-cobalt ores requires machines to withstand:

● Intense abrasion from sharp rocks and raw minerals

● Heavy impact forces during rapid excavator loading

● Extreme lateral pressure that deforms standard buckets

● High-volume dumping that stresses hydraulic joints

The FEA-optimized heavy-duty frames resist bending under maximum load, while Performance Series (PS) buckets effectively absorb harsh loading impacts to ensure long-term durability.





SEM 655D vs. XCMG ZL50GN Comparison





If you need a wheel loader capable of operating for extended periods in extreme environments, the SEM 655D is an excellent choice.

Interested in the cost-effective XCMG ZL50GN? Please click here.



Export Case

Country: Democratic Republic of the Congo

Customer Type: Mining Subcontractor

Quantity: 3 Units

Application: The machine delivers excellent cost-effectiveness and loading performance. The dual-pump hydraulic system significantly cuts cycle times, while the cooling package guarantees stable operation even in DRC's 50°C extreme heat.

For more details, please visit...



FAQ About SEM 655D Wheel Loader.



Q: Who are we?

A: We are TRUCKMAN AUTO,a manufacturer with years of experience in research and development, design, and manufacturing in China



Q: How long is the delivery time for shipping of SEM 655D Wheel Loader?

A: It depends on the order quantity, and generally takes 15-40 days.



Q: How do we ensure quality of SEM 655D?

A: Our products use only genuine, original components from well-known brands and come with official brand warranties. Furthermore, we conduct thorough factory inspections on every product before it leaves the factory.



Q: What’s our MOQ of SEM Wheel Loader?

A: For most products, the MOQ is 1 unit.
