Advanced XCMG XE215G 21 Tons Crawler Excavator For DRC

Introduction



The XCMG XE215G 21-ton crawler excavator provides proven durability and an excellent cost-to-performance ratio for the DRC's demanding mining extraction and infrastructure construction sectors.

The premium operator station features a new pressurized cabin, which provides a comprehensive improvement in comfort and safety. It is equipped with a high-power automatic hot and cold AC system, an enlarged suspension seat, and an 8-inch instrument panel with a touch screen.

This heavy excavator serves as a highly economical and practical hauling option for small mine construction, river dredging, and municipal construction.





What is the XE215G 21 Tons Excavator?



This heavy earthmoving machine customized for the international mining market combines a high-power six-cylinder Isuzu CC-6BG1TRP engine and a large displacement main pump. It boasts the following specialized configurations:

● High-power six-cylinder engine: Provides a sufficient power margin, convenient maintenance, and good oil adaptability.

● Positive flow control system: Paired with a large displacement main pump, it ensures fast response, high output efficiency, and good operation sensitivity.

● New pressurized cabin: Provides a comprehensive improvement in comfort and safety, equipped with a high-power automatic hot and cold AC system.

● Reinforced bucket: Features a 1.0 m³ bucket capacity, ideal for heavy-duty earthmoving.

● Wide application range: Widely used for irrigation and water conservancy, river dredging, municipal construction, and small mine construction.

It adapts exceptionally well to the realities of DRC mining zones, providing a solid balance between machine uptime, digging efficiency, and manageable maintenance costs.





Technical Specifications



Feature	Value
Engine	ISUZU CC-6BG1TRP
Rated Power	128.5kW/2100 rpm
Operating Weight	21700kg
Bucket Capacity	1 CBM
Maximum Digging Depth	6680mm
Maximum Traction Force	184kN
Main System Pressure	34.3MPa
Standard Track Shoe Width	600mm
Cabin	Pressurized cabin, with AC



Why It Is Suitable for DRC Mining Projects



1. Demanding Pit Road and Digging Conditions

DRC copper-cobalt mine roads and small mine construction sites typically feature:

● Deep mud, steep inclines, and unpaved laterite tracks.

● Hard rocky soils requiring continuous high-power penetration.

● Complex restricted terrains that demand precise and fast machine response.

The 184 kN maximum traction force and the positive flow control system deliver massive digging power and fast response for navigating tough rocky terrains and steep inclines.



2. Hot Climate and Heavy-Duty Challenges

Central African mining environments expose excavators to:

● Relentless high ambient temperatures under the direct sun.

● Intense heat generated during continuous heavy-duty digging shifts.

● Severe dust that easily impacts operator comfort and safety.

The new pressurized cabin, equipped with a high-power automatic hot and cold AC system, provides a comprehensive improvement in comfort and safety, preventing operator fatigue. Additionally, the high-power Isuzu engine provides sufficient power reserve and good oil adaptability to ensure stable operation in challenging climates.



3. High-Density Ore Material Demands

Handling raw, heavy copper-cobalt ores requires machines to withstand:

● Intense abrasion from sharp rocks and raw minerals.

● Heavy impact forces during rapid loading and unloading.

● Continuous heavy-duty earthmoving and rock stripping operations.

The standard 1.0 m³ reinforced bucket is ideal for continuous heavy-duty earthmoving, effectively absorbing harsh loading impacts to ensure long-term durability in small mine construction.





XCMG XE215G VS HYUNDAI HX205G Comparison





If your project involves heavy-duty digging and requires a larger displacement engine with a pressurized cabin for small mine construction, the XCMG XE215G is an excellent choice.

Interested in the highly fuel-efficient HYUNDAI HX205G for versatile earthmoving projects? Please click here.



Export Case



Country: Democratic Republic of the Congo

Customer Type: Mining Subcontractor

Quantity: 4 Units

Application: The machine delivers excellent cost-effectiveness and digging performance for copper-cobalt mine site preparation. The positive flow control system and large displacement main pump significantly cut cycle times, while the pressurized cabin guarantees comfortable operation even in the DRC's extreme heat and dust.

For more details, please visit...



FAQ About XCMG XE215G Excavator.



Q: Who are we?

A: We are TRUCKMAN AUTO,a manufacturer with years of experience in research and development, design, and manufacturing in China



Q: How long is the delivery time for shipping of XE215G Excavator?

A: It depends on the order quantity, and generally takes 15-40 days.



Q: How do we ensure quality of XE215G 21 Tons Excavator?

A: Our products use only genuine, original components from well-known brands and come with official brand warranties. Furthermore, we conduct thorough factory inspections on every product before it leaves the factory.



Q: What’s our MOQ of XCMG Excavator?

A: For most products, the MOQ is 1 unit.
