XCMG XS103J 10 Ton Single Drum Roller

About XCMG XS103J 10 Ton Single Drum Roller

The working mass of the XCMG XS103J single drum roller is 10 tons, the distributed mass of the front wheel is 4750 kg, and the distributed mass of the rear wheel is 5250 kg. It uses a hinge for steering operation and has a small turning radius. It runs with high flexibility, good maneuverability and high possibility of passing other buildings. Its compaction width can reach 1750mm. Its cab is spacious and bright, the operation console is very sensitive and simple, the engine has sufficient power, the seats are very comfortable, the fuel consumption is low, and the price is high.

XCMG XS103J 10 Ton Single Drum Roller Specification

Model: XS103J

Engine : 68kW

Operation Weight: 10tons

Vibration Frequency: 33HZ

Static Line Load: 266N/CM

Compaction Width: 1750mm

Violent Force: 140kN

Dimensions: 4895x1970x2850mm

10 ton road roller XCMG XS103J single drum roller specification only for your reference, we can manufacture other model road roller basic your request.

XCMG XS103J 10 Ton Single Drum Roller Features

XCMG XS103J single drum roller is a good machine with easy operation and high compaction density. Its engine power is 68kw and its climbing ability is very powerful. It is a powerful roller. If you want to compact asphalt or cement, you can consider this 10-ton road roller. It meets the compaction requirements of various working conditions, and its compact size makes it very suitable for compaction work such as municipal and urban and rural road paving and maintenance.

XCMG XS103J 10 Ton Single Drum Roller Advantage

XCMG XS103J single drum roller adopts a fully hydraulic system, which allows it to complete corresponding operations conveniently and effortlessly in a short period of time. It is also equipped with a wheel side reduction drive axle, which transmits large torque and can complete the work normally even under severe working conditions. It can also be equipped with an optional cam wheel for compacting non-clay soil, and can also be used for compacting sticky and fine-grained sand and gravel materials with low water content. This improves its flexibility of use and can create more for customers.
